Core Functional Features
◈
Working capacity from 10L to 10000L.
◈
Suitable for high viscosity material of 10,000~180,000cps.
◈
Integrated internal circulation system for maximum effect.
◈
System design and manufacture process reach GMP standards.
◈
Lifting emulsifier includes emulsifying pot, platform, and controllers.
◈
Advanced mixing, dumping, and cooling circulation mechanism.
Material Quality: Pipe construction design with glass window to monitor material running. Adopted SS304 and SS316 for best corrosion resistance and high-temperature performance.
Operation: Homogeneous stirring and paddle stirring can be used separately or simultaneously. Material granulation, emulsification, uniform mixing, and dispersion can be completed in a short time.
Technical Specifications
| Model |
Capacity |
Homogenizer Motor |
Stir Motor |
Dimension (mm) |
Total Power (KW) |
Limit vacuum |
| KW |
r/min |
KW |
r/min |
L |
W |
H |
Steam |
Electric |
| SME-AE5 | 5L | 0.37 | 3000 | 0.18 | 63 | 1260 | 540 | 1600 | 2 | 5 | -0.09 |
| SME-AE10 | 10L | 0.75 | 3000 | 0.37 | 63 | 1300 | 580 | 1600 | 3 | 6 | -0.09 |
| SME-AE50 | 50L | 3 | 3000 | 1.1 | 63 | 2600 | 2250 | 1950 | 9 | 18 | -0.09 |
| SME-AE100 | 100L | 4 | 3000 | 1.5 | 63 | 2750 | 2380 | 2100 | 13 | 32 | -0.09 |
| SME-AE200 | 200L | 5.5 | 3000 | 2.2 | 63 | 2750 | 2750 | 2350 | 15 | 45 | -0.09 |
| SME-AE500 | 500L | 11 | 3000 | 4 | 63 | 3650 | 3300 | 2850 | 24 | 63 | -0.08 |
| SME-AE1000 | 1000L | 15 | 3000 | 5.5 | 63 | 4200 | 3650 | 3300 | 30 | 90 | -0.08 |
Application Scope
| Hair conditioner | Facial mask | Moisturizing lotion | Suncream |
| Skin care | Shea butter | Body lotion | BB Cream |
| Cream | Hair cream | Cosmetic paste | Foundation |
| Hair color | Face cream | Eye serum | Hair gel |
| Cheese | Milk butter | Ointment | Ketchup |
| Mustard | Peanut butter | Mayonnaise | Toothpaste |
Advanced Component Details
Mixing Paddle: Double ways mixing with scraper, 316L stainless steel, 0-63 rpm.
Homogenizer Head: Designed to apply high shear forces for uniformity and consistency.
Operation Screen: Siemens touch screen, easy to learn and operate for full automatic process.
Bottom Homogenizer: SUS316L high shear with Siemens motor drive, 0-3000rpm variable speed.
Frequently Asked Questions
Q1: Are you a professional manufacturer for these machines?
Yes, we are a factory with more than 20 years of manufacturing experience, specializing in cosmetic, pharmaceutical, and food machinery.
Q2: What is the warranty period and after-sales service?
The machine comes with a one-year warranty. After the warranty period, we continue to offer lifetime after-sales services and technical support.
Q3: How do you ensure the quality of the machine before delivery?
Our quality control team tests the performance and running speed of every machine. We also provide testing videos or invite customers for on-site verification.
Q4: Is the equipment difficult to operate for new staff?
No, the machines feature a user-friendly Siemens touch screen and "fool-style" operation design. We also provide instructional videos and manuals.
Q5: Can the machines be customized according to specific requirements?
Yes, most of our machines are customized designs based on the customer's specific production requirements and material characteristics.
Q6: What materials are used in the construction of the mixers?
We use high-grade SS304 and SS316L stainless steel to ensure superior corrosion resistance and compliance with GMP standards.
